INFRA Products

The INFRA system is specifically developed for remote construction site monitoring. With INFRA you can monitor and measure vibration, air blast, noise, dust, crack movement, underwater shockwaves, weather, moisture, temperature and much more. Have a look at our product catalogue and let us know if you need more information or guidance.



Wireless

Vibration monitor

Wireless triaxial vibration monitor – INFRA C22

INFRA C22 – wireless triaxial vibration monitor, a wireless triaxial geophone and data logger built into the same compact unit. The vibration monitor has GSM/GPRS-communication, GPS position and time synchronization.

The INFRA C22 is Sigicom’s latest innovation. It is built on a brand-new hardware platform utilizing the latest technologies, such as modular communication. This will give you unparalleled reliability as well as being future proof.
It works with INFRA Net (our web application) in the same way as the other INFRA sensors and data loggers.

You can easily navigate using the keyboard and colour display on the instrument.

The extremely low power consumption gives the INFRA C22 up to four months of measurement time, well ahead of all similar systems on the market.

All filtering, signal processing and detection are done digitally. Before the recording is started you only select the wanted standard that is presented in the Remote part of INFRA Net (our web application).

Wireless vertikal vibration monitor - INFRA C20 - Sigicom

Wireless vertical vibration monitor – INFRA C20

INFRA C20 – wireless vertical vibration monitor, wireless geophone and data logger built into the same compact unit. The vibration monitor has GSM/GPRS-communication, GPS position and time synchronization.

The INFRA C20 is Sigicom’s latest innovation. It is built on a brand-new hardware platform utilizing the latest technologies, such as modular communication. This will give you unparalleled reliability as well as being future proof.
It works with INFRA Net (our web application) in the same way as the other INFRA sensors and data loggers.

You can easily navigate using the keyboard and colour display on the instrument.

The extremely low power consumption gives the INFRA C20 up to seven months of measurement time, well ahead of all similar systems on the market.

All filtering, signal processing and detection are done digitally. Before the recording is started you only select the wanted standard that is presented in the Remote part of INFRA Net (our web application).

Triaxial vibration monitor

Wireless triaxial vibration monitor – INFRA C12

INFRA C12 – wireless triaxial vibration monitor, wireless geophone and data logger built into the same compact unit. The vibration monitor has GSM/GPRS-communication. All filtering, signal processing and detection are done digitally.

Before the recording is started you only select the wanted standard that is presented in the Remote part of INFRA Net. The INFRA C12 works with INFRA Net the same way as the other INFRA sensors and data loggers.

sigicom-infra-c10-remote-digital-wireless-geophone-and-a-data-logger-vibration-monitor

Wireless vertical vibration monitor – INFRA C10

INFRA C10 – a small wireless vertical vibration monitor, wireless geophone and data logger built into the same compact unit, with GSM/GPRS-communication. All filtering and signal processing is done digitally and before the measurement is started you chose the measurement standard that you want to measure according to in the remote part of INFRA Net (web application).
The INFRA C10 works with INFRA Net (web application) the same way as the other INFRA sensors and data loggers.

INFRA C10 acts as a combined data logger and sensor in the INFRA-system when it comes to remote changes, reporting, etc.



Measure Vibrations in Atex zone 1/21

Vibration monitor in explosive atmospheres – INFRA C22 Ex

INFRA C22 Ex a measure vibrations in explosive atmospheres (ATEX zone 1/21) such as refineries and petroleum processing plants. It is designed for INFRA C22 and has full functionality of INFRA C22 and works with INFRA Net in the same way as the other INFRA sensors and data loggers.

Wired

Infra-Master-Datalogger

INFRA Master – data logger

INFRA Master is a complete battery operated data logger with a built-in GSM/GPRS modem and built-in GSM antenna. The logger has two outgoing connections for the INFRA bus cable and  A series of available sensors can be connected to a single INFRA Master.
There is also a connection for an external GSM antenna.
The front panel consists of four buttons (easy operation) and a LCD screen with 4 lines, each can display up to 20 characters.
INFRA Master is either operated with an internal lead-acid battery or connected to mains. The data is stored on the exchangeable CompactFlash card. The INFRA Master contains no measurement electronics and needs no calibration.

INFRA Mini – data logger

The INFRA Mini is a data logger with GSM and large internal memory. It features an integrated triple band (900/1800/1900 MHz) GSM with GPRS. Sigicom INFRA Mini is an economical multichannel field monitoring system for vibration, noise, air overpressure, acceleration, inclination, level, pore pressure and much more. INFRA Mini is powered wid Alkaline batteries.
A series of available sensors can be connected to a single INFRA Mini.

Weight 3.5 kg.

Omgivningspåverkan

INFRA Micro – data logger

INFRA Micro is a complete digital data logger with possibility of enclosure, high capacity data storage and flexible communication capabilities. Data is automatically sent via the internal or external modem to a database on the Internet. Data is sent on scheduled times and when a trigger has occurred. SMS with event data can be sent directly from the instrument to a number of cell phones. Project administration, data presentation, reports, analysis and graphs can easily be performed with INFRA Net.

INFRA Point, vibration monitor, construction site monitoring

INFRA Point

INFRA Point – a vibration monitor with a small, robust and traceable sensor (vertical or triaxial geophopne).

The INFRA Point is built on a brand-new hardware platform utilizing the latest technologies, such as modular communication. This will give you unparalleled reliability as well as being future proof. INFRA Point has up to 12 months of continuous monitoring on internal rechargeable batteries (for the vertical geophone).
The monitor works with INFRA Net in the same way as the other INFRA sensors and data loggers.

It can be used for measuring vibration from blasting, piling or other foundation work.

Note that this product is only available in Sweden, Norway and Finland.

Vertical vibration sensor

INFRA V10

INFRA V10 vertical geophone, measures the vibrations according to many different standards. It can be used for measuring vibration from blasting, piling, traffic etc. It can also measure acceleration that can affect sensitive equipment. Adjustments between a wide range of standards can easily be set from a connected master unit.

Construction site monitoring

INFRA V12

INFRA V12 triaxial geophone, measures according to many different standards. It is easy to mount on wall or floor/ground. Measures vibration from blasting, piling, compaction, traffic etc. Discomfort measurements according to most international standards e.g. Swedish standards SS460 48 61, ISO 2631-2 and German DIN 4150-3. Acceleration measurements for sensitive electronic equipment according to SS-ISO 8569.

Construction site monitor, mining

INFRA S10/S11

INFRA Air Blast Microphone S10/S11 measures air blast pressure to valid national and international standards. It measures both maximum values for each minute and also a complete air blast record.

Designed for vertical mounting on a wall, pole or tripod. S10 is very rugged.

Sound level meter

INFRA S50

With INFRA S50 Sound Level Meter it is easy to perform unattended monitoring of Noise from Building activities and traffic.

The Sound Level Meter is connected to the INFRA buscable with a T-connector.

INFRA S50 is a type 1 meter. It measures simultaneously max level and equivalent level with a selectable time interval (5 seconds – 20 minutes). It is also possible to set a trig level for a recording of a sound clip with up to 10 seconds duration. In INFRA Net it is possible to listen to the sound clip to identify the reason for a high level. It is also possible to apply a frequency analysis (third octave). Measuring range 20-135 dBA/dBC

All data from the sound level meter is recorded in the INFRA Master and can be automatically sent with GPRS to your database. You can connect more than one sound level meter to one INFRA Master. It is also possible to combine the Sound Level Meter with Geophones.

Speed monitoring, radar

INFRA X20SR

The INFRA X20SR Speed radar offers a convenient way to measure speed on moving objects. Together with other parts of the INFRA system, it allows for monitoring correlation between the speed of a passing object and resulting environmental parameters such as noise and vibration.

Monitor dust

INFRA X20DM2

INFRA X20DM2 Dust Monitor is a high quality sensor that simultaneously measures the airborne particle concentrations of PM10, PM2.5, PM1.0 and TSP.
Intended for continuous monitoring of dust particles from demolition, construction works and traffic. Connects directly to an INFRA data logger with the INFRA bus cable.

INFRA X20WXT

INFRA X20WXT weather station 4 channel is a small, lightweight and high quality sensor that simultaneously measures the following parameters:

  • wind speed
  • wind direction
  • rain intensity or relative humidity
  • air temperature

All settings, such as Interval time, is selected via INFRA Net and can be handled remotely.

Remote monitoring

INFRA Net

With INFRA Net – software you can view real time data and information from your INFRA systems online. It is easy to manage a large number of INFRA Systems with INFRA Net. By building, administrate and report your projects directly in INFRA Net you will save time and increase your productivity.

Based on the projects and measurement points you can easily extract reports in PDF format that can be sent directly to your customer.

The software contains a powerful analysis function allowing you to generate different types of charts and curves from transient and interval data. INFRA Net’s remote control enables you to change measurement settings, connection schedule and much more directly from your office or anywhere you have an Internet connection. Live presentation of data, alerts/alarms transmitted from our server via e-mail or SMS directly to you.
